Double Trailer-Mounted Transformer Oil Filtration Machine

Double Trailer-Mounted Transformer Oil Filtration Machine2026-03-06T01:12:52+00:00

What Is a Transformer Oil Filtration Machine with Double Axle Trailer?

A Transformer Oil Filtration Machine with Double Axle Trailer is a mobile oil purification system designed for on-site transformer oil treatment. The equipment is mounted on a double axle trailer, providing higher load capacity, improved stability, and safer transportation compared with single-axle designs.

This structure distributes the equipment weight more evenly, reducing the risk of instability or tipping when traveling on uneven roads, and ensures safer operation during field transportation an4d positioning.

Transformer Oil Purifier with Double-axle Trailer-ZANYO-03
Transformer Oil Purifier with Double-axle Trailer-ZANYO-02
Transformer Oil Purifier with Double-axle Trailer-ZANYO-01
Transformer Oil Purifier with Double-axle Trailer-ZANYO-04

Transformer Oil Purifier Functions

Removing Moisture Degassing Removing Particles
Vacuum Oil Injecting Vacuum Drying Vacuum Purification Online Work, Unattended Operation

Key Features of Double Trailer-Mounted Transformer Oil Filtration System

  • Mobility and Field Operation: Equipped with trailer wheels for easy movement. ZYM can travel long distances and operate immediately once positioned, suitable for both indoor and outdoor field use.

  • Advanced Design and Performance: Incorporates innovative designs from domestic and international oil purification industries, offering high working vacuum, high oil purifying efficiency, and high precision.

  • Control and Safety System: Optimized interlock protection, overpressure alarm, and phase sequence protection, combined with automatic pressure alarm, overload protection, constant temperature control, bubble elimination, and blowout prevention, ensuring stable and safe unattended operation.

  • Advanced Oil Purification System: Includes an atomizing system, three-dimensional separation tower, flash evaporation technology for degassing and dehydration, and high-quality multi-stage filter elements with level-by-level encryption to remove fine impurities. Primary filters are washable and reusable, preventing secondary pollution.

  • Heating and Oil Transfer System: Carbon fiber heating elements provide fast and uniform heating with excellent corrosion resistance, thermal stability, viscosity tolerance, insulation, chemical resistance, and wear resistance. Oil pumps are selected based on oil type and viscosity, using special materials and performance curves to prevent gap discharge and acetylene formation, ensuring leading treatment efficiency.

  • Transformer Oil Recycling System (Optional): Quickly removes carbon deposits caused by arcing, restoring inferior transformer oil to near-new quality.

  • Optional Configurations: PLC control, touch screen, moisture sensors, BDV oil tester, enclosed doors, mobile trailer, lighting, tool box, and special frame designs for flexible customization.

Applications of the Enclosed Transformer Oil Filtration Machine

The mobile transformer oil filtration system is widely used in industries such as electric power, petroleum, and transportation. Its trailer-mounted design allows technicians to perform oil purification directly at substations and industrial facilities.

The system is ideal for treating high-grade, ultra-high-voltage, and new transformer oil. It supports on-site filtration for transformers above 110 kV, helping maintain insulation and extend service life. It can also serve as an independent vacuum source for vacuum drying and oil filling.

Transformer Oil Filtration Machine Specifications

Index name unit 30 50 100 150 200 250 300
Flow rate L/Min 30 50 100 150 200 250 300
Working vacuum Pa ≤133
Working pressure Mpa ≤0.5
Gas content % ≤0.05
Temperature range ℃  20℃～60℃(68℉～140℉)
Power supply As per user’s option
Working noise dB(A) ≤65～85
Heating power Kw 24 30 60 90 125 136 151
Total power Kw 27 35.5 68 105 135 148 168
Inlet(Outlet) mm Φ32 Φ25 Φ44 Φ50 Φ58 Φ60 Φ65
Weight kg 520 570 920 1000 1300 1800 2200
Dimension (L) mm 1550 1550 2000 2150 2250 2300 2450
Dimension (W) mm 1200 1200 1250 1300 1300 1350 1400
Dimension (H) mm 1750 1800 2150 2250 2250 2300 2350

Why Choose ZANYO Transformer Oil Filtration Machine

ZANYO Transformer Oil Filtration Machines are designed for long-term reliable operation with extended maintenance intervals, minimizing downtime and maintenance costs. The equipment is built using high-quality brand components, ensuring durability, stable performance, and precise oil purification.

Customers can rely on 24/7 technical support, providing rapid assistance whenever needed, which makes field operation safer and more efficient. In addition, ZANYO products meet international standards and are ISO, CE, and SGS certified, guaranteeing consistent quality, safety, and compliance with global industry regulations.

This combination of trusted components, certified quality, and continuous support makes ZANYO a preferred choice for power utilities and industrial maintenance teams worldwide.

FAQ

Transformer oil is cleaned using a transformer oil filtration machine that removes moisture, gases, and solid contaminants from the oil. The process typically involves heating the oil, vacuum dehydration, degassing, and multi-stage filtration. Heating reduces oil viscosity, allowing water and gases to separate more easily. The oil then passes through a vacuum chamber where dissolved moisture and gases are extracted. Finally, precision filters remove fine particles and sludge.

This process restores the oil’s dielectric strength, insulation performance, and cooling capability, helping extend transformer service life and improve electrical reliability. Regular transformer oil purification is widely used in power plants, substations, and industrial electrical systems.

A transformer oil filtration machine works by heating the oil and using vacuum separation and filtration to remove moisture, gases, and solid impurities. The system first pumps contaminated transformer oil into a heating unit to lower viscosity and improve separation efficiency. The heated oil then enters a vacuum chamber where water and dissolved gases evaporate under reduced pressure.

After dehydration and degassing, the oil flows through multi-stage precision filters that capture suspended particles and sludge. This combination of vacuum dehydration, degassing, and fine filtration restores the oil’s insulation properties and dielectric strength, ensuring safe operation of high-voltage transformers.

The price of a transformer oil filtration machine depends on several key factors. Capacity is a primary consideration, as higher processing rates require larger pumps, heaters, and vacuum systems. The design and performance of the vacuum system, filtration precision, and number of filtration stages also affect cost, with multi-stage high-precision systems being more expensive.

Additional factors include the heating system power, level of automation (PLC control, safety features, touch-screen interfaces), and mobility or structural design, such as trailer-mounted units for field operations. Customization options, special voltage requirements, and certifications like CE, ISO, or SGS can further influence the final price.
